0.268"±0.006"/6.81±0.15mm PVC 19 VATC CCS 75 Ohm CATV Coaxial Cable For Use in Longer CATV Run Lengths

Name: 0268quot0006quot681015mm PVC 19 VATC CCS 75 Ohm CATV Coaxial Cable For Use in Longer CATV Run Lengths
Brand: Zion communication OR OEM
Price: 1 USD

Brand Name : Zion communication OR OEM

Model Number : VATC Cable

Certification : UL, ETL, CE, RoHS

Place of Origin : China

MOQ : 30 KM

Payment Terms : T/T, L/C

Supply Ability : 1000KM / Month

Delivery Time : Normally 15 working days

Packaging Details : 500M, 1000M, Wooden Drum, Pallet

Inner Conductor : 0.040"/1.02mm/18 AWG CCS

Dielectric : 0.181"/4.6mm Foamed PE

Shield 1 : 0.187"/4.75mm Bonded Aluminum PET

Shield 2 : Aluminum braid wire 55% coverage

Jacket : 0.268"±0.006"/6.81±0.15mm PVC

Jacket Thickness : 0.030"/0.76mm

Contact Now

19 VATC CCS 75 Ohm CATV coaxial Cable NO.7100424



Construction Parameters:
Inner Conductor	0.040"/1.02mm/18 AWG CCS
Dielectric	0.181"/4.6mm Foamed PE
Shield 1	0.187"/4.75mm Bonded Aluminum PET
Shield 2	Aluminum braid wire 55% coverage
Jacket	0.268"±0.006"/6.81±0.15mm PVC
Jacket Thickness	0.030"/0.76mm
Application	For Use in Longer CATV Run Lengths
Electrical Characteristics:
Inner Conductor Resistance	The Max. at 20℃ shall be < 87 Ω/km 26.6Ω/1000ft

Capacitance	52 ±3 pF/m 15.9 ±0.9 pF/ft
Impedance	75 ± 3 Ω
Return loss	between 5 and 1000MHz: > 22dB
Velocity of Propagation	0.85
Sparker Test (VAC)	4

Mechanical and Envrionmental Properties
Cable bend radius	10 times the cable diameter
Operating Temp Range	-20 ℃ to 60℃
Cable diamensions	0.268"±0.006"/6.81±0.15mm PVC

Cross Section














Attenuation(20℃):
Frequency (MHZ)	Max Attenuation(dB/100ft)	Max Attenuation (dB/100m)
5	0.58	1.90
55	1.60	5.25
83	1.95	6.40
187	2.85	9.35
211	3.05	10.00
250	3.30	10.82
300	3.55	11.64
350	3.85	12.63
400	4.15	13.61
450	4.40	14.43
500	4.66	15.29
550	4.90	16.08
600	5.10	16.73
750	5.65	18.54
865	6.10	20.01
1000	6.55	21.49

Order Informations:
Marking	HELLOSIGNAL 19 VATC CCS CATV COAXIAL CABLE 7100424 ×××M/FT
Package	Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …
Delivery time	Normally 25 days after received the deposit.
Brand	HELLOSIGNAL®OR OEM
